TPA-1 Top Adjustable Valve

Product Description: The Top Adjustable Valve is designed to be simple and easily adjustable, providing effective control over the pressure within lubrication systems. It works in conjunction with the TOP feed pump to regulate the pressure in the pipes, ensuring optimal performance of the lubrication system.

Key Features:

• Simple structure with easy adjustability.
• Effectively regulates pressure in lubrication systems.
• Designed to work with TOP feed pumps.

Technical Specifications:

• Model: Top Adjustable Valve (100)
• Pressure Adjustment Range: 0.20.8 MPa (28 kgf/cm²)
• Weight: 9.91 ounces (281 grams)

Dimensions:

• Height: 3.94 inches (100 mm)
• Width: 1.57 inches (40 mm)
• Depth: 1.18 inches (30 mm)

Applications:

• Suitable for various lubrication systems.
• Ideal for industrial applications where precise pressure control is necessary.
